Dutch Seam

Dutch Seam on siding, mix of MRD150 and MRD110, aluminum 1.0mm, PVDF finish colour Black (02)
Dutch Seam on siding, mix of models MRD194, MRD150, MRD110, aluminum 1.0mm, PVDF finish colour Ascot White (10)
Dutch Seam on roof, model MRD194, aluminum 0.8mm, PVDF finish colour Black (02)



Standing Seam panel. Concealed fasteners.

Installation : Vertically, on full surface or open framing. On roof, minimum slope 2:12.

Coverage sizes : 279mm (11”), 381mm (15”), 489mm (19 ¼”) width. Length cut upon request.  Minimum length 0.61m (2 feet).

Material : Painted steel 24ga., painted aluminum 0.8mm (0,032”), 1.0mm (0,040”). High resistance PVDF finish (Kynar 500® PVDF or Hylar 5000®).

Fixation: Patented fasterner system making easier the expansion and contraction of panels to reduce the oil canning effect.

Available with or without stiffening ribs and striations.



Clip system for the panel fastening. Concealed fastener system compatible with all models.



PVDF finishes standard colors (steel and aluminum). Color may have slight lot-to-lot variations.
Black
02
Classic Bronze
01
Medium Bronze
03
Harford Green
27
Forest Green
11
Hemlock Green
30
Teal
19
Patina Green
12
Chocolate Brown
04
Boysenberry
25
Redwood
07
Mission Red
08
Sierra Tan
09
Rawhide
15
Concord Cream
05
Almond
36
Sandstone
06
Regal Blue
18
Slate Blue
21
Rocky Grey
16
Siam Blue
14
Charcoal Grey
62
Slate Grey
20
Dove Grey
13
Ascot White
10
Bone White
26
PVDF matte colors (steel and aluminum). Color may have slight lot-to-lot variations.
Almond
36
Thunder Grey
34
Anchor Grey
37
Ash Grey
38
Char Brown
29
Matte Black
32
PVDF Premium Finish (steel and aluminum). Color may have slight lot-to-lot variations.
Antique Patina
24
Champagne
31
Coppertone
23
Titanium
35
Silversmith
Discontinué / Discontinued
Brite Red
17
Anodized finishes (aluminum only). Color may have slight lot-to-lot variations.
Clear Satin Anodized
70
Dark Bronze Anodized
71
Galvalume Plus (steel only)
Galvalume Plus
97
