Square

Square tile 4-fold, steel 24ga., PVDF finish colour Silversmith Premium (28). 45 degrees installation.
Square tile 4-fold, steel 24ga., PVDF finish colours Ascot White (10), Dove Grey (13), Charcoal Grey (62). 45 degrees installation
Square tile 2-fold, steel 24ga., PVDF finish colour Almond (36). Aligned staggered installation.



Square tile. Concealed fasteners.

Installation : Horizontally, vertically, 45 degree, aligned, staggered rows, on full surface or open framing.

Standard coverage sizes :

tile 4-fold (siding and roofing): 343 mm (13 ½x 13 ½). 0.12 m2 (1.27 ft2) Higher relief. On roof : minimum slope 5:12.
tile 2-fold (siding): 330 mm (13x 13). 0.11 m2 (1.17 ft2). Lower relief. Horizontal, vertical installation only.

Other dimensions are custom-made.

Material : Pre-painted steel 24 ga. and pre-painted aluminum 0.8mm (0,032”), PVDF finish Kynar® 500 or Perspectra Series™, more than 40 colors available. Also available with stainless steel, copper and Galvalume Plus. High resistance finish.

                              2 PLIS (SIDING)                                 4 PLIS (SIDING/ ROOF)



PVDF finishes standard colors (steel and aluminum)
Black
02
Classic Bronze
01
Medium Bronze
03
Harford Green
27
Forest Green
11
Hemlock Green
30
Teal
19
Patina Green
12
Chocolate Brown
04
Boysenberry
25
Redwood
07
Mission Red
08
Sierra Tan
09
Rawhide
15
Concord Cream
05
Almond
36
Sandstone
06
Regal Blue
18
Slate Blue
21
Rocky Grey
16
Siam Blue
14
Charcoal Grey
62
Slate Grey
20
Dove Grey
13
Ascot White
10
Bone White
26
PVDF matte colors (steel and aluminum)
Almond
36
Thunder Grey
34
Anchor Grey
37
Ash Grey
38
Char Brown
29
Matte Black
32
PVDF Premium Finish (steel and aluminum)
Antique Patina
24
Champagne
31
Coppertone
23
Titanium
35
Silversmith
28
Brite Red
17
Anodized finishes (aluminum only)
Clear Satin Anodized
70
Dark Bronze Anodized
71
Galvalume Plus (steel only)
Galvalume Plus
97
Perspectra Series (steel only)
Metro Brown
8228
Mahogany
8719
Dark Brown
8229
Coffee
8326
Tan
8315
Charcoal
8306
Stone Grey
8305
Regent Grey
8730
Black
8262
White
8317
Forest Green
8307
Medium Green
8329
Mist Green
8256
Turquoise
8258
Slate Blue
8260
Royal Blue
8790
Heron Blue
8330
Orange
8234
Red
8250
Bright Red
8386
Tile Red
8259
Antique Linen
8696
Ivory
8802
Metallic Grey
QC7500
